1. The use of high-precision ceramic ferrules with smaller concentricity errors and inner hole diameters provides better insertion loss and return loss, avoiding the degradation of transmission performance and the damage of optical transceiver devices.
2. The use of advanced grinding technology and grinding equipment to ensure that the surface of the optical fiber is free of scratches and flaws, the optical fiber center grinding offset, the optical fiber dent and the ceramic end surface curvature radius and other technical parameters meet the specified standards.
3. All components have been optically tested, and the tests are in line with ROHS standards;
4. Comply with ANSI/TIA/EIA and ISO/IEC for durability, moisture resistance, coupling stress, fiber tensile force and adaptability to harsh environments such as humidity, extreme temperature, insertion force and cable tensile stress, impact and vibration Require;
5. The insertion loss is small, the return loss is large, the interchangeability is good, the repeated plugging performance is excellent, and it is easy to use;
6. Suitable working temperature (-40°C~+75°C), storage temperature (-40°C~+85°C)
|
Type Performance |
Single mode |
Multi mode |
||
|
|
UPC |
APC |
UPC |
|
|
Insertion Loss |
Max |
≤ 0.3dB |
≤ 0.3dB |
≤ 0.3dB |
|
|
Typical |
0.2dB |
0.2dB |
0.2dB |
|
Return Loss |
≥ 50dB |
≥ 55dB |
≥ 35dB |
|
|
Testing Wavelength |
1310nm & 1550nm |
850nm & 1300nm |
||
|
Technical performance（500 times） |
IL < 0.1dB |
|||
